Bilstein 24-184847 B6 4600 Front Shock Absorber for 1994-01 Dodge Ram 1500/2500
Part # 24-184847 SKU BIL24-184847
Highlights
- Adjustable damping
- No (Non-Adjustable)
- Application specific
- Yes (Dodge Ram 1500/2500)
- Boot included
- Yes, Blue Straight Boot
- Bushing material/color
- Rubber, Black
- Collapsed length
- 9.36 in (237.8 mm)
- Extended length
- 13.56 in (344.5 mm)
- Gas/hydraulic
- Gas Pressure
- Hardware included
- Yes
- Item length
- 21.9 in (package length)
- Lower mount
- Bushed Eyelet (14.4mm)
- Material
- Steel Body, Rubber Bushings, Chrome-Plated Shaft
- Mounting style
- Upper Stud / Lower Bushed Eyelet (14.4 mm)
- Position
- Front
- Prop 65 warning
- Warning applies
- Reservoir
- No
- Segment
- Light Truck
- Shaft material
- Steel, Chrome Plated
- Shock absorber system
- Monotube
- Shock absorber type
- Gas
- Shock body color/finish
- Yellow, Painted
- Shock body material
- Steel
- Travel length
- 4.2 in (approx., based on 13.56 in extended – 9.36 in collapsed)
- Type
- Suspension Shock Absorber
- Upper mount
- Stem / Stud Mount
Description
Bilstein 24-184847 B6 4600 Front Shock Absorber for 1994-01 Dodge Ram 1500/2500
The Bilstein B6 4600 Front Shock Absorber is engineered to enhance the performance and handling of your 1994-2001 Dodge Ram 1500/2500. Designed for serious driving conditions, these shock absorbers utilize Bilstein’s advanced technology to provide remarkable stability and control, whether you're navigating through rugged terrains or cruising on the highway. The B6 4600 series is built to absorb shock effectively, ensuring a comfortable ride while maintaining excellent road feedback.
This high-performance shock absorber is constructed using durable materials that withstand the test of time and challenging environments. The monotube design allows for optimal heat dissipation, preventing fade during extended or heavy-duty use. This means that drivers can experience consistent performance over a wide range of conditions, making it an ideal choice for both work and leisure activities.
With its easy installation process, this shock absorber can significantly improve the overall ride quality of your Dodge Ram, reducing body roll and enhancing cornering stability. It is designed to accommodate lift kits and larger tires, providing flexibility for customization while still delivering a superior driving experience.
FITMENT: This shock absorber is specifically designed for the 1994-2001 Dodge Ram 1500 and 2500 models, guaranteeing compatibility and optimal performance tailored to these vehicles.
Key Features & Benefits
- Monotube design ensures superior handling and consistent performance.
- Optimized for enhanced stability, reducing body roll during cornering.
- Durable construction materials enhance longevity and reliability.
- Effective heat dissipation prevents shock fade in demanding conditions.
- Improves ride comfort, suitable for both on-road and off-road driving.
- Compatible with lift kits and larger tires for enhanced versatility.
Vehicle fitment
| Make | Model | Submodel | Years |
|---|
No vehicle matches that filter.
Fitment data from the manufacturer catalogue. Check your engine before ordering, or call us.
Specifications
| Identification | |
|---|---|
| Brand | BILSTEIN |
| Part number | 24-184847 |
| SKU | BIL24-184847 |
| UPC | 651860417936 |
| Dimensions and weight | |
| Dimensions (W × H × D) | 3.00 × 22.00 × 3.00 in |
| Material and finish | |
| Material | Steel Body, Rubber Bushings, Chrome-Plated Shaft |
| Series and warranty | |
| Series | B6 4600 Series |
| Details | |
| Adjustable damping | No (Non-Adjustable) |
| Application specific | Yes (Dodge Ram 1500/2500) |
| Boot included | Yes, Blue Straight Boot |
| Bushing material/color | Rubber, Black |
| Collapsed length | 9.36 in (237.8 mm) |
| Extended length | 13.56 in (344.5 mm) |
| Gas/hydraulic | Gas Pressure |
| Hardware included | Yes |
| Includes | Shock Absorber, Dust Boot, Hardware (as required) |
| Item length | 21.9 in (package length) |
| Lower mount | Bushed Eyelet (14.4mm) |
| Mounting style | Upper Stud / Lower Bushed Eyelet (14.4 mm) |
| Position | Front |
| Prop 65 warning | Warning applies |
| Reservoir | No |
| Segment | Light Truck |
| Shaft material | Steel, Chrome Plated |
| Shock absorber system | Monotube |
| Shock absorber type | Gas |
| Shock body color/finish | Yellow, Painted |
| Shock body material | Steel |
| Travel length | 4.2 in (approx., based on 13.56 in extended – 9.36 in collapsed) |
| Type | Suspension Shock Absorber |
| Upper mount | Stem / Stud Mount |
