Brembo 09.B570.11 UV Coated Vented Front Brake Rotor BMW X3 X4 328mm
Brembo 09.B570.11 UV Coated Vented Front Brake Rotor BMW X3 X4 328mm
Brembo OE

Brembo 09.B570.11 UV Coated Vented Front Brake Rotor BMW X3 X4 328mm

Part # 09.B570.11 SKU 568420

(No reviews) Write a Review
$108.99
In stock, ships from a US warehouse
Fits 2010-2017 BMW X3, 2015-2018 BMW X4 Full fitment list
SKU: 568420
UPC: 8020584039496
Width: 13.00 (in)
Height: 14.00 (in)
Depth: 4.00 (in)
Adding to cart… The item has been added
Shipping
Free, US only. Arrives in 2–4 days.
Returns
30-day returns. Wrong fit? Our team is here 24/7. Details
Help
Not sure it fits? +1 619-577-3602
  • Ships from US warehouses
  • Secure checkout: cards, PayPal, Google Pay
  • 5,464 positive feedback on eBay
  • Parts people on the phone, not a call centre

Highlights

Bolt pattern
5x120 mm (fits BMW X3/X4 application)
Discard thickness
26.4 mm minimum
Fixing screws
Included
Inside diameter
75 mm (center bore)
Item height
732 mm
Item length
328 mm
Item thickness
28 mm nominal
Material
High Carbon Cast Iron
Number of holes
5
Position
Front
Rotor outside diameter
328 mm (≈ 12.9 in)
Rotor style
Vented
Torque specification
140 Nm
Type
Brake Disc Rotor
Interchange number
Fits BMW X3 (2010-2017) & X4 (2015-2018), - 28i / 28d / 30i / 35i engines (L4 2L & L6 3.0L), Covers sDrive28i, xDrive28i, xDrive28d, xDrive30i, xDrive35i & X4 xDrive28i / 35i OE brake rotors.

Description

Key facts

  • Part number: 09.B570.11
  • OE REPLACEMENT: Engineered to meet or exceed OE specifications, delivering precise fit, consistent braking, and Brembo-certified quality with ECE R-90 compliance
  • VENTED COOLING: OE based vane design promotes effective heat dissipation and consistent braking performance, ensuring thermal stability and reliable operation
  • QUAILTY: Top of the line manufacturing standards help deliver a reliable fitment, performance and product quality
  • Necessary Hardware: Fixing screws and all necessary hardware required by the manufacturer in the box

The Brembo 09.B570.11 Premium UV Coated Front Disc Brake Rotor is designed as a direct replacement for select BMW X3 and X4 applications. Manufactured from High Carbon Cast Iron, this vented rotor features Brembo's solvent-free UV coating for corrosion protection across the rotor surfaces.

The rotor measures 328 mm in outside diameter with a 28 mm nominal thickness and 26.4 mm minimum thickness. Brembo UV Coated rotors are designed to meet or exceed applicable OEM specifications, and a fixing screw kit is included.

Vehicle Fitment

BMW X3: Fits select 2010-2017 applications, including xDrive30i, xDrive28i, xDrive35i, sDrive28i and xDrive28d configurations depending on model year and engine.

BMW X4: Fits select 2015-2018 xDrive28i and select 2015-2016 xDrive35i applications. Verify exact year, submodel, engine and factory brake configuration before ordering.

Key Features & Benefits

  • Premium UV Coated front disc brake rotor
  • Direct-replacement design
  • High Carbon Cast Iron construction
  • Solvent-free UV coating
  • Rust-resistant coated finish
  • 328 mm outside diameter
  • 28 mm nominal thickness
  • 26.4 mm minimum thickness
  • Vented rotor design
  • 75 mm center hole diameter
  • 5-hole configuration
  • Fixing screw kit included
  • Intelligent marking identifies part number and minimum thickness

Technical Specifications

Brand Brembo
Part Number / MPN 09.B570.11
Product Type Premium UV Coated Disc Brake Rotor
Position Front
Material High Carbon Cast Iron
Coating UV Coated
Outside Diameter 328 mm
Nominal Thickness 28 mm
Minimum Thickness 26.4 mm
Rotor Type Vented
Center Hole Diameter 75 mm
Number of Holes 5
Fixing Screws Included Yes

Installation & Compatibility

Verify the exact model year, submodel, engine and factory brake configuration before installation. Brembo recommends replacing brake pads and rotors together when appropriate to help restore braking system performance.

California Restriction

No California sales or use restriction is specified in the supplied product information.

Important Notes

  • Fits select BMW X3 and X4 applications only.
  • X3 fitment extends through select 2010-2017 applications.
  • X4 fitment extends through select 2015-2018 applications.
  • Fixing screw kit is included.
  • Verify exact vehicle and brake-system compatibility before ordering.

Fits

2010-2017 BMW X3, 2015-2018 BMW X4

Fitment data from the manufacturer catalogue. Check your engine before ordering, or call us.

Specifications
Identification
BrandBrembo OE
Part number09.B570.11
SKU568420
UPC8020584039496
Dimensions and weight
Dimensions (W × H × D)13.00 × 14.00 × 4.00 in
Material and finish
FinishUV Coated
MaterialHigh Carbon Cast Iron
Series and warranty
Details
Bolt pattern5x120 mm (fits BMW X3/X4 application)
Discard thickness26.4 mm minimum
Fixing screwsIncluded
IncludesBrake Disc, Fixing Screws
Inside diameter75 mm (center bore)
Item height732 mm
Item length328 mm
Item thickness28 mm nominal
Number of holes5
PositionFront
Rotor outside diameter328 mm (≈ 12.9 in)
Rotor styleVented
Torque specification140 Nm
TypeBrake Disc Rotor
Interchange numberFits BMW X3 (2010-2017) & X4 (2015-2018), - 28i / 28d / 30i / 35i engines (L4 2L & L6 3.0L), Covers sDrive28i, xDrive28i, xDrive28d, xDrive30i, xDrive35i & X4 xDrive28i / 35i OE brake rotors.

Shipping and returns

Shipping. Free on every order, US only. Orders arrive in 2–4 days.

Returns. 30-day returns, except in extreme cases.

Support. Our team is available 24/7 for fitment mismatches or any other reason.

Warranty. Full manufacturer guarantee.
