Brembo 09.C654.11 UV Coated Vented Front Brake Rotor Mazda 6 CX-5 2013-2019

The Brembo 09.C654.11 Premium UV Coated Front Brake Rotor is designed as a direct-replacement rotor for select Mazda 6 and Mazda CX-5 applications. Manufactured from grey cast iron, this vented front rotor features a 297 mm outside diameter, 28 mm nominal thickness and Brembo's solvent-free UV coating for corrosion protection.

Brembo UV Coated rotors are developed to meet or exceed applicable OEM specifications. The UV coating protects the rotor surfaces against corrosion, while intelligent rotor markings identify the part number and minimum thickness for easier service reference.

Vehicle Fitment

Mazda 6: Select 2014-2019 Sport and Touring applications; select 2014-2018 Grand Touring applications; additional 2018 Grand Touring Reserve and Signature applications.

Mazda CX-5: Select 2013-2015 Sport, Touring and Grand Touring applications with applicable 2.0L or 2.5L L4 engines. Verify exact year, trim, engine and factory brake configuration before ordering.

Key Features & Benefits

• Premium UV-coated front brake rotor
• Direct-replacement design for compatible applications
• Grey cast iron construction
• Vented rotor configuration
• Rust-resistant UV coating
• 297 mm outside diameter
• 28 mm nominal thickness
• 26 mm minimum thickness specification
• Designed to meet or exceed applicable OEM specifications
• Rotor marking identifies part number and minimum thickness

Technical Specifications

Installation & Maintenance

Verify the vehicle's exact year, trim, engine and factory brake configuration before installation. Brembo recommends replacing brake rotors and pads together when restoring braking performance. Follow the applicable vehicle service procedures during installation.

California Restriction

No California sales or use restriction is specified in the supplied product information.

Important Notes

• Mazda 6 fitment extends beyond the 2013-2015 range shown in the current listing.
• Mazda 6 applications begin in 2014 and extend through select 2019 models.
• Mazda CX-5 applications cover select 2013-2015 models.
• The supplied 515.00 mm overall-height value has been omitted pending verification.
• Verify exact trim, engine and brake configuration before ordering.

2014-2019 Mazda 6, 2013-2015 Mazda CX-5

Fitment data from the manufacturer catalogue. Check your engine before ordering, or call us.
