Brembo 09.7812.21 UV Coated Vented Front Brake Rotor Subaru WRX STI Toyota 86
Part # 09.7812.21 SKU 569366
Write a Review
Brembo OE
Brembo 09.7812.21 UV Coated Vented Front Brake Rotor Subaru WRX STI Toyota 86
Highlights
- Center hole diameter
- 58
- Material
- High Carbon Cast Iron
- Minimum thickness (mm)
- 28
- Nominal thickness
- 30
- Number of holes
- 5
- Outside diameter
- 326
- Overall height
- 527
- Position
- Front
- Rotor style
- Vented
- Rust resistant coating
- Yes
- Solid or vented type rotor
- vented
- Torque spec(nm)
- 100
- Type
- Brake Disc Rotor
- Interchange number
- 2004-2021 Subaru Impreza WRX STI/WRX STI Limited, WRX STI Special Edition/WRX Limited/WRX Premium, WRX STI Base/WRX STI Launch Edition, WRX STI Series.HyperBlue H4; 2018-2020 Toyota 86 Base, GT/Hakone Edition/TRD Special Edition H4.
Description
The Brembo 09.7812.21 Premium UV Coated Front Brake Rotor is designed as a direct replacement for select Subaru and Toyota performance applications. Manufactured from High Carbon Cast Iron, this vented rotor features Brembo's solvent-free UV coating for corrosion protection across the rotor surfaces.
The rotor measures 326 mm in outside diameter with a 30 mm nominal thickness and 28 mm minimum thickness. Brembo UV Coated rotors are designed to meet or exceed applicable OEM specifications and feature intelligent marking for part identification and minimum thickness information.
Vehicle Fitment
Subaru: Fits select Impreza WRX STI, WRX STI and WRX applications, including specified Base, Limited and Special Edition configurations depending on model year and factory brake setup.
Toyota: Fits select 2018-2020 Toyota 86 applications and select 2024-2025 Toyota GR86 applications. Verify the exact year, trim and factory brake configuration before ordering.
Key Features & Benefits
- Premium UV Coated front brake rotor
- High Carbon Cast Iron construction
- Direct-replacement design
- Solvent-free UV coating
- Rust-resistant coated finish
- 326 mm outside diameter
- 30 mm nominal thickness
- 28 mm minimum thickness
- Vented rotor design
- 58 mm center hole diameter
- 5-hole configuration
- Designed to meet or exceed applicable OEM specifications
- Fixing screw kit included
- Intelligent marking identifies part number and minimum thickness
Technical Specifications
| Brand | Brembo |
| Part Number / MPN | 09.7812.21 |
| Product Type | Premium UV Coated Brake Rotor |
| Position | Front |
| Material | High Carbon Cast Iron |
| Coating | UV Coated |
| Outside Diameter | 326 mm |
| Nominal Thickness | 30 mm |
| Minimum Thickness | 28 mm |
| Rotor Type | Vented |
| Center Hole Diameter | 58 mm |
| Number of Holes | 5 |
| Fixing Screw Kit Included | Yes |
Installation & Compatibility
Verify the exact model year, trim and factory brake configuration before installation. Fitment varies significantly across the listed Subaru and Toyota applications.
Brembo recommends replacing brake pads and rotors together when appropriate to help restore braking system performance.
California Restriction
No California sales or use restriction is specified in the supplied product information.
Important Notes
- Fits select Subaru and Toyota applications only.
- Do not assume continuous 2004-2021 WRX STI fitment.
- Compatibility depends on the exact model year, trim and factory brake configuration.
- Verify exact vehicle fitment before ordering.
Fits
2004-2014 Subaru Impreza, 2015-2017 Subaru WRX STI, 2018-2020 Toyota 86, 2024-2025 Toyota GR86 and 1 more
Fitment data from the manufacturer catalogue. Check your engine before ordering, or call us.
Vehicle fitment
| Make | Model | Submodel | Years |
|---|
No vehicle matches that filter.
Fitment data from the manufacturer catalogue. Check your engine before ordering, or call us.
Specifications
| Identification | |
|---|---|
| Brand | Brembo OE |
| Part number | 09.7812.21 |
| SKU | 569366 |
| UPC | 8020584781227 |
| Dimensions and weight | |
| Outside diameter | 326 |
| Dimensions (W × H × D) | 13.00 × 13.00 × 3.00 in |
| Material and finish | |
| Finish | Zinc Plated |
| Material | High Carbon Cast Iron |
| Series and warranty | |
| Details | |
| Center hole diameter | 58 |
| Includes | Mounting Hardware |
| Minimum thickness (mm) | 28 |
| Nominal thickness | 30 |
| Number of holes | 5 |
| Overall height | 527 |
| Position | Front |
| Rotor style | Vented |
| Rust resistant coating | Yes |
| Solid or vented type rotor | vented |
| Torque spec(nm) | 100 |
| Type | Brake Disc Rotor |
| Interchange number | 2004-2021 Subaru Impreza WRX STI/WRX STI Limited, WRX STI Special Edition/WRX Limited/WRX Premium, WRX STI Base/WRX STI Launch Edition, WRX STI Series.HyperBlue H4; 2018-2020 Toyota 86 Base, GT/Hakone Edition/TRD Special Edition H4. |
Shipping and returns
Shipping. Free on every order, US only. Orders arrive in 2–4 days.
Returns. 30-day returns, except in extreme cases.
Support. Our team is available 24/7 for fitment mismatches or any other reason.
Warranty. Full manufacturer guarantee.
Not sure about this part? Ask us.
Fitment, install, what else you need for the job. A parts person answers, usually within one business day.
We answer by email. No account needed.
