Wilwood 260-1333 Pull-Type Hydraulic Clutch Slave Cylinder Billet Aluminum
Wilwood 260-1333 Pull-Type Hydraulic Clutch Slave Cylinder Billet Aluminum
WILWOOD

Wilwood 260-1333 Pull-Type Hydraulic Clutch Slave Cylinder Billet Aluminum

Part # 260-1333 SKU WIL260-1333

(No reviews) Write a Review
$106.95
In stock, ships from a US warehouse
SKU: WIL260-1333
UPC: 889545067170
Width: 4.00 (in)
Height: 12.00 (in)
Depth: 4.00 (in)
Adding to cart… The item has been added
Shipping
Free, US only. Arrives in 2–4 days.
Returns
60-day free returns. Wrong fit? Our team is here 24/7. Details
Help
Not sure it fits? +1 619-577-3602
  • Ships from US warehouses
  • Secure checkout: cards, PayPal, Google Pay
  • 5,464 positive feedback on eBay
  • Parts people on the phone, not a call centre

Highlights

Bore diameter
7/8 in
Design
Pull Type
Inlet size
3/8-24 Inverted Flare Female
Length
11.75 in
Material
Billet Aluminum Body / Steel Components
Port quantity
1 (3/8-24 Inverted Flare Female Inlet)
Stroke
1-3/8 in
Type
Clutch Slave Cylinder

Description

The Wilwood 260-1333 Pull-Type Clutch Slave Cylinder is designed for hydraulic clutch systems used in performance and competition applications. Manufactured from billet aluminum, the cylinder combines high-strength construction with a plated anti-corrosion finish.

A stainless steel push rod is used in the assembly, and Wilwood specifies that the cylinder provides a longer stroke than most slave cylinders to help achieve full clutch release. It is suitable for applications such as Drag Racing, Late Model Stock, Pro Series and Off Road vehicles.

Application

Designed for compatible hydraulic clutch systems requiring a pull-type slave cylinder. This is an application-dependent component rather than a vehicle-specific direct-fit part.

Master Cylinder Recommendation: Wilwood recommends a 3/4-inch master cylinder size for this slave cylinder.

Key Features & Benefits

  • Pull-type hydraulic clutch slave cylinder
  • Billet aluminum construction
  • Plated anti-corrosion finish
  • Stainless steel push rod
  • Longer stroke than most slave cylinders
  • Designed to provide sufficient travel for full clutch release
  • Suitable for Drag Racing applications
  • Suitable for Late Model Stock and Pro Series applications
  • Suitable for Off Road applications
  • Recommended for use with a 3/4-inch master cylinder

Technical Specifications

Brand Wilwood
Part Number / MPN 260-1333
Product Type Clutch Slave Cylinder
Operation Pull Type
Body Material Billet Aluminum
Body Finish Plated Anti-Corrosion Finish
Push Rod Material Stainless Steel
Recommended Master Cylinder Size 3/4 in

Installation & Compatibility

Confirm the clutch linkage geometry, mounting arrangement, hydraulic system requirements and available travel before installation. This slave cylinder is intended for compatible custom and performance hydraulic clutch systems rather than a specific vehicle application.

California Restriction

No California sales or use restriction is specified in the supplied product information.

Important Notes

  • This is a pull-type clutch slave cylinder.
  • Wilwood recommends a 3/4-inch master cylinder.
  • Verify hydraulic system compatibility and mounting requirements before ordering.

Specifications
Identification
BrandWILWOOD
Part number260-1333
SKUWIL260-1333
UPC889545067170
Dimensions and weight
Length11.75 in
Dimensions (W × H × D)4.00 × 12.00 × 4.00 in
Material and finish
FinishPlated / Corrosion Resistant
MaterialBillet Aluminum Body / Steel Components
Series and warranty
Details
Bore diameter7/8 in
DesignPull Type
IncludesSlave Cylinder, Push Rod Assembly
Inlet size3/8-24 Inverted Flare Female
Port quantity1 (3/8-24 Inverted Flare Female Inlet)
Stroke1-3/8 in
TypeClutch Slave Cylinder

Shipping and returns

Shipping. Free on every order, US only. Orders arrive in 2–4 days.

Returns. 60-day free returns, except in extreme cases.

Support. Our team is available 24/7 for fitment mismatches or any other reason.

Warranty. Full manufacturer guarantee.
