Wilwood 140-12569 D154 Pro-Series Rear Disc Brake Kit Chevrolet C10 GMC C15

The Wilwood 140-12569 D154 Rear Disc Brake Kit is designed for select Chevrolet and GMC truck applications using the compatible 5-lug rear axle configuration with a 2.42-inch offset. The system features 12.19-inch UltraLite HP 32 rotors with hats and D154 2-piston calipers finished in black powder coat.

This rear brake package is application-specific and requires careful verification of axle offset, bolt pattern and wheel clearance before installation. Some 15-inch wheels may be compatible, but wheel clearance must be checked using the applicable Wilwood installation diagram before purchase.

Vehicle Fitment

Chevrolet Applications: Select C10, C10 Suburban, K5 Blazer and 1987 R10 applications using the compatible 5-lug rear axle configuration.

GMC Applications: Select C15, C15 Suburban, Jimmy and 1987 R1500 applications. 5-lug only with 2.42-inch offset. Verify exact year, model, axle configuration and wheel clearance before ordering.

Key Features & Benefits

• D154 rear disc brake kit
• Designed for compatible Chevrolet and GMC 5-lug applications
• 2.42-inch axle offset configuration
• 12.19-inch UltraLite HP 32 rotor and hat configuration
• D154 2-piston calipers
• Black powder-coated caliper finish
• Rear disc/drum configuration
• Application-specific brake upgrade package

Technical Specifications

Installation & Compatibility

Confirm the vehicle's rear axle configuration, 5-lug pattern and 2.42-inch offset before installation. A universal parking-brake cable kit may require modification to the cable or vehicle depending on the specific application.

This kit may fit some 15-inch wheels; however, wheel clearance is not guaranteed. Check the wheel-clearance diagram in the applicable installation instructions before purchasing or installing the kit.

Important Notes

• 5-lug applications only.
• Designed around a 2.42-inch rear axle offset.
• Some 15-inch wheels may fit; verify wheel clearance before purchase.
• Parking-brake cable installation may require modification depending on the vehicle.
• Do not assume compatibility based only on C10 or C15 model designation.

1975-1986 Chevrolet C10, 1975-1984 GMC Jimmy, 1975-1986 Chevrolet C10 Suburban, 1979-1986 GMC C1500 and 10 more

Fitment data from the manufacturer catalogue. Check your engine before ordering, or call us.
